STM Vertical Turning Lathe VTL100

VL / VD 510

Table(LxW)(mm)

650x410

Travel(XxYxZ)(mm)

550x410x480

Spindle

Belt Drive Spindle BBT40 - 8000 RPM 10000/12000 RPM(optional) Direct Drive Spindle BBT40 - 8000 RPM 10000/12000/15000 RPM (optional)

DL2114

Table(LxW)(mm)

2000x1200

Travel(XxYxZ)(mm)

2100x1400x800

Spindle

BT 50 - 6000 / ZF Germany

DL2619

Table(LxW)(mm)

2500x1500

Travel(XxYxZ)(mm)

2600x1900x900

Spindle

BT 50 - 6000 / ZF Germany 15/18.5 (18.5/22 Opt.)

VL / VD 610

Table(LxW)(mm)

800x450

Travel(XxYxZ)(mm)

640x450x500

Spindle

Belt Drive Spindle BBT40 - 8000 RPM 10000/12000 RPM(optional) Direct Drive Spindle BBT40 - 8000 RPM 10000/12000/15000 RPM (optional)

DL3119

Table(LxW)(mm)

3000x1500

Travel(XxYxZ)(mm)

3100x1900x900

Spindle

BT 50 - 6000 / ZF Germany 15/18.5 (18.5/22 Opt.)

VL / VD 850

Table(LxW)(mm)

1000x500

Travel(XxYxZ)(mm)

850x510x510

Spindle

Belt Drive Spindle BBT40 - 8000 RPM 10000/12000 RPM(optional) Direct Drive Spindle BBT40 - 8000 RPM 10000/12000/15000 RPM (optional)

VL / VD 1000

Table(LxW)(mm)

1100x510

Travel(XxYxZ)(mm)

1000x510x510

Spindle

Belt Drive Spindle BBT40 - 8000 RPM 10000/12000 RPM(optional) Direct Drive Spindle BBT40 - 8000 RPM 10000/12000/15000 RPM (optional)

DL3225

Table(LxW)(mm)

3000x2000

Travel(XxYxZ)(mm)

3200x2500x1000

Spindle

BT 50 - 6000 / ZF Germany 15/18.5 (18.5/22 Opt.)

VL / VD 1050

Table(LxW)(mm)

1200x600

Travel(XxYxZ)(mm)

1100x650x610

Spindle

Belt Drive Spindle BBT40 - 8000 RPM 10000/12000 RPM(optional) Direct Drive Spindle BBT40 - 10000 RPM 12000/15000 RPM (optional) Belt Drive Spindle BBT50 - 6000 RPM 8000 RPM(optional) Direct Drive Spindle BBT50 - 8000 RPM 10000 RPM (optional)

DL4225

Table(LxW)(mm)

4000x2000

Travel(XxYxZ)(mm)

4200x2650x1000

Spindle

BT 50 - 6000 / ZF Germany 18.5/22 (22/26 Opt.)

VL / VD 1300

Table(LxW)(mm)

1450x650

Travel(XxYxZ)(mm)

1300x700x700

Spindle

Belt Drive Spindle BBT40 - 8000 RPM 10000/12000 RPM(optional) Direct Drive Spindle BBT40 - 10000 RPM 12000/15000 RPM (optional) Belt Drive Spindle BBT50 - 6000 RPM 8000 RPM(optional) Direct Drive Spindle BBT50 - 8000 RPM 10000 RPM (optional)

DL3230

Table(LxW)(mm)

3000x2200

Travel(XxYxZ)(mm)

3200x3150x1000

Spindle

BT 50 - 6000 / ZF Germany 22/26

VL / VD 1600

Table(LxW)(mm)

1800x800

Travel(XxYxZ)(mm)

1600x800x750

Spindle

Belt Drive Spindle BBT40 - 8000 RPM 10000/12000 RPM(optional) Direct Drive Spindle BBT40 - 10000 RPM 12000/15000 RPM (optional) Belt Drive Spindle BBT50 - 6000 RPM 8000 RPM(optional) Direct Drive Spindle BBT50 - 8000 RPM 10000 RPM (optional)

DL4230

Table(LxW)(mm)

4000x2200

Travel(XxYxZ)(mm)

4200x3150x1000

Spindle

BT 50 - 6000 / ZF Germany 22/26

VL / VD 2090

Table(LxW)(mm)

2200x900

Travel(XxYxZ)(mm)

2000x900x850

Spindle

Belt Drive Spindle BBT40 - 8000 RPM 10000/12000 RPM(optional) Direct Drive Spindle BBT40 - 10000 RPM 12000/15000 RPM (optional) Belt Drive Spindle BBT50 - 6000 RPM 8000 RPM(optional) Direct Drive Spindle BBT50 - 8000 RPM 10000 RPM (optional)

VG 610

Table(LxW)(mm)

800 x 450

Travel(XxYxZ)(mm)

640x450x500

Spindle

Belt/Direct BBT40 8000 rpm (Opt: 10000/12000rpm)

VG 850

Table(LxW)(mm)

1000 x 500

Travel(XxYxZ)(mm)

850x510x510

Spindle

Belt/Direct BBT40 8000 rpm (Opt: 10000/12000rpm)

VG 1050

Table(LxW)(mm)

1200 x 600

Travel(XxYxZ)(mm)

1050x650x610

Spindle

Belt/Direct BBT40 8000 rpm (Opt: 10000/12000rpm)

VFX400

Travel(XxYxZ)(mm)

600x(520 F 220 - R300)x500

C Axis Rotation

360⁰

A Axis Rotation

30 / -110⁰

VD510

Table(LxW)(mm)

650 x 400

Travel(XxYxZ)(mm)

510x400x330

Spindle

Direct Drive Spindle BT30 - 10000 RPM (standard) 12000-20000 RPM (optional)

EGP-2020

Swivel Over Table(mm)

Ø210

Distance Between Center(mm)

200

Max. Grinding Diameter (mm)

Ø200

VR850

Pallet Size(LxW)(mm)

500 x 850

Travel(XxYxZ)(mm)

850x510x510

Spindle

Belt Drive Spindle (standard) BBT40 - 8000 RPM 10000/12000 RPM (optional) Direct Drive Spindle (optional) BBT40 - 10000 RPM 12000/15000 RPM (optional)

EGP-2520

Swivel Over Table(mm)

Ø250

Distance Between Center(mm)

200

Max. Grinding Diameter (mm)

Ø230

EGP-2550

Swivel Over Table(mm)

Ø250

Distance Between Center(mm)

500

Max. Grinding Diameter (mm)

Ø230

EGP-2575

Swivel Over Table(mm)

Ø250

Distance Between Center(mm)

750

Max. Grinding Diameter (mm)

Ø230

EGP-25100

Swivel Over Table(mm)

Ø250

Swivel Over Table(mm)

1000

Max. Grinding Diameter (mm)

Ø230

EGP-3260

Swivel Over Table(mm)

Ø320

Swivel Over Table(mm)

600

Max. Grinding Diameter (mm)

Ø300

EGP-32100

Swivel Over Table(mm)

Ø320

Swivel Over Table(mm)

1000

Max. Grinding Diameter (mm)

Ø300

EGP-32150

Swivel Over Table(mm)

Ø320

Distance Between Center(mm)

1500

Max. Grinding Diameter (mm)

Ø300

EGA-2550

Swivel Over Table(mm)

Ø250

Distance Between Center(mm)

500

Max. Grinding Diameter (mm)

Ø230

EGA-2575

Swivel Over Table(mm)

Ø250

Distance Between Center(mm)

750

Max. Grinding Diameter (mm)

Ø230

EGA-25100

Swivel Over Table(mm)

Ø250

Distance Between Center(mm)

1000

Max. Grinding Diameter (mm)

Ø230

EGA-3260

Swivel Over Table(mm)

Ø320

Distance Between Center(mm)

600

Max. Grinding Diameter (mm)

Ø300

EGA-32100

Swivel Over Table(mm)

Ø320

Distance Between Center(mm)

1000

Max. Grinding Diameter (mm)

Ø300

EGA-32150

Swivel Over Table(mm)

Ø320

Distance Between Center(mm)

1500

Max. Grinding Diameter (mm)

Ø300

VTL60

Max. Turning Diameter(mm)

⌀700/L 150

X/Z Travel

X -40/+350 Z -770

Turret Type

Hydraulic

VTL80

Max. Turning Diameter(mm)

⌀850/L 150

X/Z Travel

X -40/+430 Z -870

Turret Type

Hydraulic

VTL100

Max. Turning Diameter(mm)

⌀1100/L 150

X/Z Travel

X -40/+530 Z -920

Turret Type

Hydraulic

Description

  • Our Vertical Turning Lathe is engineered for exceptional performance in vertical turning applications, specifically designed to handle the most demanding heavy-duty metal cutting tasks with unparalleled precision and reliability Incredible Cutting Ability: Engineered with advanced technology to ensure precise and efficient cutting, making it ideal for the most challenging metalworking tasks.
  • Heavy-Duty Performance: Designed for rigorous applications, our lathe can handle substantial workloads without compromising on accuracy.
  • Rigid Cutting Capability: Perfect for industries requiring high levels of precision and consistency, our machine guarantees stability and performance even under the toughest conditions.
  • Built to withstand heavy usage, ensuring long-term reliability and performance.
  • Achieve perfect cuts every time with our advanced cutting technology.
  • Suitable for a wide range of industrial applications, making it a valuable addition to any manufacturing setup.
  • Increase your operational efficiency with a machine designed for high-speed, high-precision cutting.

Specification

VTL100
Unit
Values

Max. Swing Diameter
Mm
1200
Max. Turning Diameter
Mm
⌀1100/L 150
Standard Turning Diameter
Mm
850
Max. Turning Height
Mm
900
Chuck Size
Mm
530(630)

X-Axis
-
-40/+530
Z-Axis
-
920

RPM
-
2000/1500

Type
-
Hydraulic
No.of Stations(Nos)
-
12(10)
Tool Shank Size
Mm
32

Machine Weight
Kg
11000
Power Supply
KVA
40

Product Video

View our machines in action. Explore their true potential and discover how STM can enhance your manufacturing capabilities. Watch the video now and experience the future of machining with STM.
